Second Level Protection

1. Complies with IEC 61643.11
2. Low residual voltage output, fast overvoltage response
3. Failure indication function – red window indicates failure
4. Thermally controlled overheating trip mechanism, linked to indicator window
5. High-energy zinc oxide varistor, high discharge current capacity
6. Pluggable modular design, 35mm DIN rail installation
7.Nominal Discharge Current (8/20us)In:20 kA
Maximum Discharge Current (8/20us) lmax:40 kA
